Product Details:
|
| Condition: | New | Max. Output Power: | 1000W 1500w 2000w 3000w |
|---|---|---|---|
| Usage: | Metal Welding | Single Pulse Energy: | 110J |
| Pulse Width: | 0.1ms~40ms | Wavelength: | 1064nm |
| Focal Spot Diameter: | 0.1mm-3.0mm | Dimensions: | 1170mm*590mm*1250mm |
| Warranty: | 2 Year, 2year | Laser Source Brand: | RAYCUS |
| Laser Head Brand: | BOAO LASER | Servo Motor Brand: | FUJI |
| Guiderail Brand: | TPI | Control System Brand: | Cypcut |
| Weight (KG): | 650 KG | Key Selling Points: | Mold Laser Repairing |
| Applicable Industries: | Manufacturing Plant, Machinery Repair Shops | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Marketing Type: | New Product 2023 |
| Warranty Of Core Components: | 2 Year | Core Components: | Other, LASER SOURCE |
| Laser Type: | Fiber Laser | Sample Test: | Available |
| Welding Depth: | ≤2mm | Pulse Frequency: | ≤100hz |
| Weld Laser: | Laser Welding | Weld Machin Laser: | Laser Weld Machin Price |
| Product Name: | Automatic Fiber Laser Welding Machine | Function: | Metal Welding Service |
| Port: | Tianjin, China |
|
Model
|
BMII –1000 BMII -1500 BMII-2000 BMII-3000
|
|
3-axis stroke of work bench
|
X=300mm, Y=200mm (X, Y can be adjusted manually and Z-axis can be lifted)
|
|
Bearing of work bench
|
≤100kg
|
|
Whole Machine Weight
|
700kgs
|
|
Power supply
|
380V ±10%/50Hz Or 220V±10%/50Hz
|
|
Laser type
|
CW FIBER
|
|
Laser wavelength
|
1060nm
|
|
Pulse width
|
≤20ms
|
|
Laser Spot Diameter
|
0.1-3.0mm adjutable
|
|
Maximum laser power
|
1000W /1500W/2000W/3000W
|
|
Pulse frequency
|
≤100Hz
|
|
Laser output focus length
|
150mm
|
|
Laser cooling
|
Water cooling
|
|
Observing system
|
Microscope (360° adjustable)
|
|
Protection gas
|
One line (xenon)
|
|
Welding wire diameter
|
0.1mm-1.6 mm
|
