Product Details:
|
| Condition: | New | Max. Output Power: | 3000w |
|---|---|---|---|
| Usage: | Metal Welding | Single Pulse Energy: | 110J |
| Pulse Width: | 0.1-10ms | Wavelength: | 1064nm |
| Focal Spot Diameter: | 0.2-2mm | Dimensions: | 1000x550x1150mm |
| Warranty: | 2 Years | Laser Source Brand: | RAYCUS |
| Laser Head Brand: | Raytools | Servo Motor Brand: | FUJI |
| Guiderail Brand: | HIWIN | Control System Brand: | Cypcut |
| Weight (KG): | 400 KG | Key Selling Points: | Flexible Manufacturing |
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Marketing Type: | Hot Product 2023 |
| Warranty Of Core Components: | 2 Years | Core Components: | Engine, LASER SOURCE, LASER HEAD, WATER CHILLER |
| Application: | Welding Products | Laser Power: | 1000W 2000W 3000W (optional) |
| Laser Type: | Continuous Fiber Laser | Keywords: | 5 Axis Automatic Laser Welding Machine |
| Welding Mode: | Continuous Welding | Cooling System: | Water Cooled |
| Laser Source: | Raycus IPG JPT Max Optional | Welding Materials: | Stainless Steel Carbon Steel Etc( Metal Laser Welding Machine ) |
| Advantage: | Fully Automatic | Power Supply: | AC220V/380V |
|
Model
|
BFW1000/BFW1500/BFW2000/BFW3000
|
|
Laser Type
|
CW FIBER LASER
|
|
Laser Wavelength
|
1060nm
|
|
Laser Maximum Power
|
1000W /1500W/2000W/3000W
|
|
Welding Spot
|
0.1-5.0 MM ADJUTABLE
|
|
Total Power Consumption
|
8kw /10KW /12KW /14KW
|
|
Min line width
|
≤0.15mm
|
|
Cooling System
|
Water Cooling
|
|
Continous working time
|
24 Hours
|
|
Environment temperature
|
0-35°C
|
|
Power requirements
|
380V/3 Phases /50Hz or 60Hz
|
